The uniform 0.2 milliradian Horus Grid provides precise references for bullet drop, wind holds and second-shot corrections, without holding in empty space.
Legacy Reticle
TREMOR2®
The advanced legacy reticle that preceded TREMOR3®, combining the Horus Grid, Time of Flight Wind Dots and refined mil markers.
TREMOR2® at a glance
0.2 MRADHorus Grid
Wind DotsTime of Flight
0.1 MRADChevron mil markers
Original Reticle Diagram
TREMOR2® reticle diagram
Archived Horus Vision TREMOR2® feature diagram
Reticle Technology
Inside the TREMOR2® reticle
Original features from the Horus Vision archive.
Patented Time of Flight Wind Dots express wind holds in wind-speed values, such as mph, kph or m/s. They can be calibrated for the shooter's ballistics and density altitude.
Chevron mil markers subtend 0.1 milliradians for target range estimation, with vertical references for target height and horizontal references for target width.
Ballistic Tools
Horus Ballistics App
Use the Horus Ballistics App to calibrate Wind Dots for your ballistics and explore the current Horus tools.
